Automatic Voltage Regulator (AVR) AVR 15A

Language Translator

OEM No/Model:	165mm145mm55mm
Minimum Order:	1PCS
Export Ratio:	91% - 100%
Samples:	Charge
Place of Region:	CHONGQING
Payment Terms:	L/C,D/A,D/D,CASH
Delivery Time:	WITHING 5-7 DAYS
Market Type:	After Market
Packing:	NORMAL BOX
Current Export Market:	North America,South America,Western Europe,Eastern Europe,Eastern Asia,Southeast Asia,Mid East,Africa

Product Details

Product Name:

Automatic Voltage Regulator (AVR) AVR 15A

Product Attribute:

Voltage:24v

Current:4A

Size:165mm*145mm*55mmmm

Current Type:DC

Phase:Three Phase

Application:

GENERATOR

Product Description:

Automatic Voltage Regulator (AVR)
AVR 15A

GAVR-15A type Genset AVR/General AVR/GAVR 15A Data

Model	GAVR-15A
Sensing Input Voltage	220/400VAC,1phase 2wire
Power Input Voltage	180~240VAC, 1phase 2wire
Output Voltage	Max.90VDC@240VAC input
	Current Continuous 6A
	Intermittent 12A for 10SEE
	Resistance Min.10 Max 100
Voltage Build-up	esidualvolts at AVR teminal>5VAC
External Volts Adjustment	+/-7%with 1K 1watt trimmer
Unit Power Dissipation	Max.8Watt
Under Frequency Protection 60Hz system presets knee point at 57Hz
Factory Settings	50Hz system presets knee point at 47Hz

We also provide other models of AVRs as follows:

GAVR-15A type Genset AVR/General AVR/GAVR 15A

STAMFORD

AVR

LEROY

SOMER

General

AVR

Basler

series

MeccAlte

series

Marelli

series

Marathon

series

Chager

AS440

R230

GAVR-8A

EA04C

EA06A/UVR6

M40FA640

SE350

ZH-CH28 5A

SX440

R250

GAVR-12A

EA05A

Automatic Voltage Regulator (AVR) AVR 15A
