AVR Automatic Voltage Regulator (AVR) SX460A
Voltage:24v
Current:4A
Size:165mm*145mm*55mmmm
Current Type:DC
Phase:Three Phase
GENERATOR
Power AC Brushless Single Phase Generator AVR SX460 is the standard AVR offered with generators in the lower power bands, achieving voltage regulation in the order of 1.5 %. A feature of this (and all AVR's) is that output voltage is reduced with speed below the normal operating level, to assist the engine or prime mover to recover after sudden application of a heavy load. This is an ideal choice for applications where a generator set is to be run in a stand-alone application where no specialist requirements exist.
Model Number: SX460
Product name: AVR SX460
Voltage: 190~260VAC
Frequency: 50/60Hz
Current continuous: 4A DC
Weight: 0.55kg
Packing size: 165mm*145mm*55mm
INPUT Voltage Jumper selectable 95-132V ac or 190-264V ac Frequency 50-60 Hz nominal Phase 1 OUTPUT Voltage max 90V dc at 207V ac input Current continuous 4A dc Intermittent 6A for 10 secs Resistance 15 ohms minimum REGULATION +/- 1% (see note 1) THERMAL DRIFT 0.05% per deg. C change in AVR ambient (note 2)
