Product Name:
Automatic Voltage Regulator (AVR) AVR 8A
Product Attribute:
Voltage:24v
Current:4A
Size:165mm*145mm*55mmmm
Current Type:DC
Phase:Three Phase
Application:
GENERATOR
Product Description:
Automatic Voltage Regulator (AVR)
AVR 8A
Description-----
GAVR-8A is Universal 8 Amp 1/2 Wave Self Excited Dip-Switch Programmable be Automatic Voltage Regulator, which is suitable for brushless generator.
*SensingInput Voltage 220/400VAC,1phase 2wire
*Power Input Voltage 180~240VAC, 1phase 2wire
*Output Voltage Max.90VDC@240VAC input
Current Continuous 6A
Intermittent 6A for 10SEE
Resistance Min.10 Max 100
*Voltage Build-up esidualvolts at AVR teminal>5VAC
*External Volts Adjustment +/-7%with 1K 1watt trimmer
*Unit Power Dissipation Max.8Watt
*Under Frequency Protection 60Hz system presets knee point at 57Hz
*(Factory Settings) 50Hz system presets knee point at 47Hz
|
GAVR-8A |
|
Input |
Sensing Voltage |
220/400VAC,1phase 2wire |
|
Power Voltage |
180~240VAC, 1phase 2wire |
|
Voltage Jumper selectable |
95-132V ac or 190-264 Hz nominal |
|
Frequency |
50-60 Hz nominal |
|
Output |
Voltage max |
90V dc at 207V ac input |
|
Current continuous |
2A dc |
|
Current intermittent |
5A for 10 secs |
|
Resistance |
20 ohms minimum |
|
Voltage Build-up |
esidualvolts at AVR teminal>5VAC |
|
External volts adjustment |
|
