Product Name:
Automatic Voltage Regulator (AVR) AVR R450
Product Attribute:
Voltage:24v
Current:4A
Size:165mm*145mm*55mmmm
Current Type:DC
Phase:Three Phase
Application:
GENERATOR
Product Description:
Automatic Voltage Regulator (AVR)
AVR R450
R450 Leroy Sommer Alternator AVR :
Leroy Somer R450 AVR,R450 is analog Automatic Voltage Regulator with transistors. for LSA 46.2, 47.2, 49.1 and LSA 50.2 altern
2.Applications
§ standard : for LSA 46.2, 47.2, 49.1 and LSA 50.2 alternators.
§ optional : for LSA 42.2, 43.2, 44.2. alternators Adapted to the SHUNT, AREP or PMG excitation systems.
3.R450 Main characteristics
§ Voltage regulation +/- 0.5% at steady state and constant speed.
§ Control by transistor means that the regulation quality is independant of applied load.
§ Phase to phase voltage sensing.
§ Suitable for high levels of vibration and harsh environments.
§ Integrated "LAM" and " auto adaptative LAM" system to cope with load impacts applied to the engine
§ AREP or PMG excitation with normal or fast response.
§ Single or three phase voltage sensing with optional module.
§ Rotating switch facilitating selection.
Voltage |
230± 2V |
Voltage Steady Range |
± 1V |
Starting Excitation Voltage |
1.5V |
Loading Capacity |
With 110% loading, the regulator can work normally |
Output Voltage Steady on hot and cool condition |
2V |
Temperature float on Output Voltage |
2V |
