Automatic Voltage Regulator (AVR) AVR EA05A

Language Translator

OEM No/Model:	165mm145mm55mm
Minimum Order:	1PCS
Export Ratio:	91% - 100%
Samples:	Charge
Place of Region:	CHONGQING
Payment Terms:	L/C,D/A,D/D,CASH
Delivery Time:	WITHING 5-7 DAYS
Market Type:	After Market
Packing:	NORMAL BOX
Current Export Market:	North America,South America,Western Europe,Eastern Europe,Eastern Asia,Southeast Asia,Mid East,Africa

Product Details

Product Name:

Automatic Voltage Regulator (AVR) AVR EA05A

Product Attribute:

Voltage:24v

Current:4A

Size:165mm*145mm*55mmmm

Current Type:DC

Phase:Three Phase

Application:

GENERATOR

Product Description:

Automatic Voltage Regulator (AVR)
AVR EA05A

EA05A 5 Amp self excited brushless type genset voltage regulator is an universal AVR and compatible replacement for Basler KR7, Airman DST-100-2, Markon 36245, Markon MD1C, Petrus 265-06S.

Features

Voltage regulation < ±0.5%
EA05A / EA05A-NL : 220/380/440 VAC programmable input
EA05A-B : 95~130 VAC programmable input
Rugged compact design
With under frequency protection
Soft start voltage ramping
EMI suppression
Built-in high capacity 5 Amp fuse

Sensing Input	Voltage 220/380/440 VAC 1 phase 2 wire DIP switch selectable Frequency 50/60 Hz DIP switch selectable *EA05A-B : Voltage 95~130 VAC 1 phase 2 wire
Power Input	Voltage 100~300 VAC 1 phase 2 wire *EA05A-B : Voltage 50~150 VAC 1 phase 2 wire
Output	Voltage Max. 63 VDC @ 220 VAC input Max. 90 VDC @ 240 VAC input Current Continuous 5A Intermittent 7A for 10 sec. Resistance Min. 15 ohm , Max. 100 ohm *EA05A-B : Voltage Max. 45VDC @ 120 VAC input
Volts Regulation	< ±0.5% (with 4% engine governing)
Build Up Voltage	Residual volts at AVR terminal > 5 VAC
External Volts Adjustment	7% with 1K ohm 1 watt trimmer
Unit Power Dissipation	Max. 8 watts
Soft Start Ramp Time	3 sec.
EMI Suppression	Internal electromagnetic interference filtering
Thermal Drift	0.03% per°C change in AVR ambient
Under Frequency Protection (Factory Setting)	60Hz system presets knee point at 55Hz 50Hz system presets knee point at 45Hz
Environment	Operation Temperature -40~70°C Storage Temperature -40~85°C Relative Humidity Max. 95% Vibration 3G @ 100~2KHz
AVR Controls Function	VOLTS : Voltage Adjustment STAB : Stability Adjustment U/F : To Set the U/F Knee Point (*U/F : Under Frequency Protection)
Dimensions	101.0 x 69.0 x 49.5 mm
Weight	183 g ±2%

Automatic Voltage Regulator (AVR) AVR EA05A
