Automatic Voltage Regulator (AVR) AVR UVR6

Automatic Voltage Regulator (AVR) AVR UVR6
Automatic Voltage Regulator (AVR) AVR UVR6
OEM No/Model:

165mm*145mm*55mm

Minimum Order:

1PCS

Export Ratio:

91% - 100%

Samples:

Charge

Place of Region:

CHONGQING

Payment Terms:

L/C,D/A,D/D,CASH

Delivery Time:

WITHING 5-7 DAYS

Market Type:

After Market

Packing:

NORMAL BOX

Current Export Market:

North America,South America,Western Europe,Eastern Europe,Eastern Asia,Southeast Asia,Mid East,Africa

Product Details

Product Name:

Automatic Voltage Regulator (AVR) AVR UVR6

Product Attribute:

Voltage:24v

Current:4A

Size:165mm*145mm*55mmmm

Current Type:DC

Phase:Three Phase

Application:

GENERATOR

Product Description:

Automatic Voltage Regulator (AVR) AVR UVR6

General Features

Brushless Generator AVR Automatic Voltage Regulator Generator/Alterantor part AVR UVR6 is an advanced design electronic regulator that ensure excellent performance of the alternators while they are running and druing starting. The eregulator is equipped with a complete protection system against operation conditions that could be dangerous for the machine. The AVR regulator is suitable fore being used with all Mecc Alte alternators and is standard supply for power outputs above or equal to 85KVA, both three phase and single phase.

The terminal board is equipped with indications to help connection and avoid errors.

Data Sheet

Brushless Generator AVR Automatic Voltage Regulator Generator/Alterantor part AVR UVR6
Sensing/Power input
Voltage 220-480VAC single phase/ Three phase 50/60hz
Power input 50-280VAC(1,2), 50/60HZ
Magnetic Field Output
Voltage Max 63VDC at 220VAC input
Current Continuous 6A Max, Intermittent 7A for 10 seconds

Automatic Voltage Regulator (AVR) AVR UVR6
Automatic Voltage Regulator (AVR) AVR UVR6
