Digital Meter JX800 UTV
Voltage:12v
Type:Speedometer
Gasoline、Motorcycle、Motorboat、ATV
Applicable models Use of motor vehicle emissions below 900cc
Features
1. Working stability , LCD display accurate
2.indicator lights laser engraving technology meet, show a clear three-dimensional
3.combination meter display using independent manner, to better meet customer needs
Product performance
item
Limit parameter
remark
Working temperature
-20~75
Relative humidity
45%~75%
Operating voltage range
DC 10~18V
Rated voltage
DC 12V
Rated current
80mA
Maximum speed display
140KM/h, simulation of dynamic instructions
stepper motor, each cell 1000r/min engine speed
display,maximum 8000r/min (dynamic
instruction display)
Maximum cumulative mileage
99999 Km
Light description
Lights turn left,turn right light,four-wheel drive display instructions for the green; high-beam instructions for the blue; R,batteries,engine oil instructions for the red
Oil level
Segment LED analog instruction, short of oil and flashing alarm
temperature
Stepper motor dynamic instructions pointer
Dimensions
