Excavator Parts Common Rail Turbocharger 2674A256 315-9810 458-8357 569-6097 3159810 4588357 5696097 For Caterpillar C7.1

Excavator Parts Common Rail Turbocharger 2674A256 315-9810 458-8357 569-6097 3159810 4588357 5696097 For Caterpillar C7.1
Excavator Parts Common Rail Turbocharger 2674A256 315-9810 458-8357 569-6097 3159810 4588357 5696097 For Caterpillar C7.1
Previous
Next
OEM No/Model:

2674A256,315-9810,458-8357,569-6097,3159810,4588357,5696097

Minimum Order:

10PCS

Export Ratio:

91% - 100%

Samples:

Charge

Sample Price:

10

Place of Region:

China

Payment Terms:

T/T

Price Terms:

FOB

Delivery Port:

CHONGQING

Delivery Time:

20 DAYS

Market Type:

After Market

Packing:

BLUE BOX PACKING

Current Export Market:

North America,South America,Western Europe,Eastern Europe,Eastern Asia,Southeast Asia,Mid East,Africa

Product Details

Product Name:

Excavator Parts Common Rail Turbocharger 2674A256 315-9810 458-8357 569-6097 3159810 4588357 5696097 For Caterpillar C7.1

Product Attribute:

Engine Model:C7.1

G.W:19kg

Application:

Caterpillar

Product Description:

Turbocharger For Caterpillar

Turbocharger Catalogue for Caterpillar
S/N Part # Application
1 49189-04810 4FD 312D/313D/TD04HL
2 49189-02490 TD04H 312C/311CU S4K
3 49189-02450 TD04H 3118/312B S4K
4 49179-00460 TD06H 120B/31 2/312A S4K
5 49179-00451 E200B 5I-5015 S6K
6 49179-02260 E120B/E200B S6K
7 49179-02350  320C S6K
8 49135-03320 307D 4M40
9 314522 100-5865 0R6599  950F
10 167575 115-1181,0R6904 938F
11 4P4681 7C5624 Cat325 3116T
12 166773 OR6743,102-8410 325B
13 71169 0R9795 1760389 330B
14 310130 3LM-319 4N8969 D33C,3306
15 310135 3LM-373 7N7748 3306
16 310258 4LE-504 4N9554 3306
17 186514 1W1227 3306 966D
18 409410-5006 7N4651 T04B91 215B 3304
19 74195 237-5272 C7,325C,3126
20 173106 198-1845 3126,938G,959G
21 168834 C7,325C,3126
22 175273 C7,B2G,325D
23 10709880002 B2  323D/320D C6.6
24 11589880028 C7 328D B1G TCD2013L
25 313658 3306,S40S 330 966F
26 2W1744 OR5792 TV6135 3306
27 465032-0001 0R5841 6N7203 D342,D8K
28 168443 219-9711 3306B
29 174755 2485376 S31OC C9 330C
30 310C080 171847 C9,330C
31 250-7700 10R2969 S310 C9 330D
32 216-7815 1OR0823 S310G C9 938G 950G
33 178477 10R0183 300G  C10
34 172313 10R0208  S310G C10
35 709310-0001 194-1116 3298953 C10 3176C
36 465969-5 TV81 4P2783 SR4 3412C D8N
37 1W5580 TV81 3408 3508
38 TV81 8N6554, 4W9104 3408 3406
39 6N7960 130-6233 7W5969 3512
40 7W9409 466610-2 TV92 3512
41 198749 0R6155 9Y9204 3516
42 331010000290 3516 3512
43 168665 130-5469 0R7075 3406C
44 14969880000 S41OG 3406B/C/E C15/16
45 714508-0003 190-6210 C12
46 762548-5004 247-2964 GTA4502S C13
47 247-2969 712402-0070 C13
48 762552-5003 247-2965 C13
49 GT4702B 743279-0004 239-5583 C13
50 752538-0005 252-4590 252-4589 C13/C15
51 704604-0007 167-9271 0R7310 C15/C16
52 238-5102 10R1975 74131-0005 C15
53 211-6959 172830 10R0569 S310G C18
54 267-8658 266-0195 238-8685 S310G C18
55 720538-5002 196-2776 0R7910 345B 3176
56 701756-1 153-0703 0R7234 988G 3456
57 274-6296 750525-5021  C15
58 466807-0001 10R-0435 TV85 3508B 3516B
59 TW8107 465052-0003 7W4866 CAT3508 3412

Turbocharger Model Nm(lbf.in) Nm(lbf.in) HousingMaterial Nm(lbf.in)
3LD 3LE
3FD 3FE 3FJ
4LE 4LF 4LG
4LEV 4LEK 4LFK 4LGK 4LGZ		 N/A
N/A
N/A
20.3(180)		 8.5(75)
8.5(75)
8.5(75)
8.5(75)		 N/A
N/A
N/A
N/A		 8.5(75)
8.5(75)
8.5(75)
8.5(75)
6" 6D 6LD 16.3(144) 10.9(96) N/A N/A
H1AH1B H1C H1D H1E
H2A H2B H2C H2D H2E H2S
H3 H3B HC3 HC3B HT3 HT3B
BHT3B BHT3C BHT3E
HT4B HT4C

HC5A		 26(230)
20.3(180)
N/A
N/A
N/A

20.3(180)		 8.5(75)
8.5(75)
8.5(75)
8.5(75)
N/A

N/A		 N/A
N/A
3504959
3539458
1/4 in UNF nut
M8 nut
N/A		 8.5(75)
8.5(75)
8.5(75)
11.3(100)
8.5(75)
12(106
8.5(75))
HX20 N/A N/A N/A 3.4(30)
HX25 HX27 N/A N/A N/A 8.3(74)*
HX30 HX32 N/A N/A N/A 8.5(75)
HX35 HX40 20(230) 8.5(75) N/A N/A
HX50 HX52 HX55 20.3(180) N/A 3535399
3595763
Aluminium		 8.5(75)
11.3(100)
8.5(75)
HX60 HT60 N/A N/A 3504959
3539458
Aluminium		 8.5(75)
11.3(100)
8.5(75)
HP70 HX80 HP81 20.3(180) N/A N/A 8.5(75)
HX80  HX85 20.3(180) N/A Aluminium
Cast Iron		 8.5(75)
12(106)
HT80 20.3(180) N/A 1/4 in UNF nut
MS nut		 8.5(75)
12(106)
HX82 20.3(180) N/A Aluminium
Cast Iron		 8.5(75)
12(106)
HX83 20.3(180) N/A N/A 12(106)
HT100 N/A N/A N/A 8.5(75)
HY30 HY35 HY40 HY55 N/A N/A N/A 8.5(75)

COMPATIBLE MODELS FOR PART NUMBER 569-6097

PAVING COMPACTOR

CP56B CP68B CP74B CP76B CS56B CS68B CS74B CS78B CS79B

TRACK-TYPE TRACTOR

D4 D5 D5R2 D6K D6K2 D6N

WHEEL-TYPE SKIDDER

525D

ASPHALT PAVER

AP600 AP600F AP655 AP655F AP655F L

WHEELED EXCAVATOR

M322D2 M320D2 M322D2 MH M324D2 MH

PIPELAYER

PL61

WHEEL-TYPE LOADER

924K 930K 938K

ENGINE - INDUSTRIAL

C7.1

EXCAVATOR

320 320D 320D GC 320D2 FM 323 323D L 323D2 323D2 L 326 326 GC 326D2 323GC 326D2 L 326GC 329D2 329D2 L 330 330 GC 330D2 330D2 L 333 GC

MOTOR GRADER

120 140 GC

TRACK-TYPE LOADER

953K



Excavator Parts Common Rail Turbocharger 2674A256 315-9810 458-8357 569-6097 3159810 4588357 5696097 For Caterpillar C7.1
Excavator Parts Common Rail Turbocharger 2674A256 315-9810 458-8357 569-6097 3159810 4588357 5696097 For Caterpillar C7.1
