Generator Auto Start Control Panel Module ATS AMF 4520 Generator Controller DSE4520

Product Name:

Generator Auto Start Control Panel Module ATS AMF 4520 Generator Controller DSE4520

Product Attribute:

Current Type:DC

Application:

GENERATOR

Product Description:

Generator Auto Start Control Panel Module ATS AMF 4520 Generator Controller DSE4520

KEY BENEFITS for Controller DSE4520

Ultimate size to feature ratio

Automatically transfers between mains (utility) and generator (DSE4520 only)

Hours counter provides accurate information for monitoring and maintenance periods

User-friendly set-up and button layout for ease of use

Multiple parameters are monitored simultaneously which are clearly displayed on the largest back-lit icon display in its class

The module can be configured to suit a wide range of applications

Compatible with a wide range of CAN engines, including tier 4 engine support

Uses DSE Configuration Suite PC Software for simplified configuration

Licence-free PC software

IP65 rating (with optional gasket) offers increased resistance to water ingress

KEY FEATURES of DSE4520 Controller

Largest back-lit icon display in its class

Fully configurable via the fascia or PC using USB communication

Extremely efficient power save mode

3 phase generator sensing

3 phase mains (utility) sensing (DSE4520 only)

Generator/load power monitoring (kW, kV A, kV Ar, pf)

Generator/load current monitoring and protection

Fuel and crank outputs (configurable when using CAN)

4 configurable DC outputs (2 for DSE4510)

3 configurable analogue/digital inputs

4 configurable digital inputs

Configurable staged loading outputs

CAN and alternator speed sensing in one variant

3 engine maintainance alarms

Engine speed protection

Engine hours counter

Engine pre-heat

Engine run-time scheduler

Battery voltage monitoring

Start on low battery voltage

Configurable remote start input

1 alternative configuration

Comprehensive warning, electrical trip or shutdown protection upon fault condition

LCD alarm indication

Event log (15)
